Model No. |
AS12TW4RYETD00B |
Basic Specifications |
Air Conditioner Type |
Inverter |
Air Conditioner Function |
Cooling |
Cooling Capacity (BTU/h) |
12000 |
Cooling Capacity (W) |
3517 |
Rated Voltage (V) |
220-240V, 50 Hz |
Rated Input Power (W) |
1125 |
Rated Current (A) |
5 |
Climate Class |
T1 |
EER (W/W) |
3.13 |
Noise Level (dB) Indoor (Mid Fan Speed) |
33 |
Noise Level (dB) Outdoor |
51 |
Connecting Pipe Length (m) |
4 |
Cooling Specifications |
Refrigerant |
R32 |
Refrigerant Amount (kg) |
0.55 |
Evaporator Type |
Copper Tube Evaporator |
Condenser Type |
Copper Tube Condenser |
Evaporator Fin Type |
Golden Hydrophilic Fin |
|
|
Compressor Type |
Rotary, Inverter |
Operating Features |
Temperature Control Range |
16°C-30°C |
Display Type (Indoor) |
LED |
Display Dimmer |
YES |
Vertical Auto Swing Louver |
YES |
Horizontal Auto Swing Louver |
YES |
Indoor Unit Filter |
Washable PP Filter |
24 Hour Timer |
YES |
Sleep Operation |
YES |
Super Function |
YES |
Auto Restart |
YES |
Self Cleaning |
YES |
Refrigerant Leak Detection |
YES |
Operation/Control |
Wirelesss Remote Controlled |
3 Speed and Auto Indoor Fan Control |
YES |
Packing Information |
Indoor Unit Net Dimension (LxWxH) mm |
850 x 270 x 208 |
Indoor Unit Packing Dimension (LxWxH) mm |
900 x 335 x 260 |
Outdoor Unit Net Dimension (LxWxH) mm |
660 x 240 x 482 |
Outdoor Unit Packing Dimension (LxWxH) mm |
785 x 345 x 530 |
Indoor unit Net Weight (kg) |
8.5 |
Indoor unit Gross Weight (kg) |
11 |
Outdoor unit Net Weight (kg) |
20.5 |
Outdoor unit Gross Weight (kg) |
25.5 |
Warranty Information |
Compressor |
12 Years |
Main Board (PCB) |
2 Years |
Spare Parts |
2 Years |
Other |
2 Years Free Service |
|
|
|
|
|
|
|
|
|
